OSRAM LED MODULE 12,4W 40° 4000K

Compatible with conventional MR16 lamps. 5 year guarantee

Κωδικός : #4052899541818

Nominal wattage	12.30 W
Construction wattage	12.30 W
Claimed equiv. conventional lamp power	50 W
Nominal voltage	35.2 V
Input voltage range	34…37 V
Type of current	DC
Nominal current	350 mA

Total useful luminous flux [PICOS]	1050 lm
Luminous efficacy	84 lm/W
Luminous flux	926 lm
Luminous intensity	2100 cd
Nom. useful luminous flux 120° [PICOS]	1018 lm
Color temperature	4000 K
Color rendering index Ra	≥90
Light color LED	White
Light color (designation)	Neutral White
Standard deviation of color matching	≤3 sdcm
Rated peak intensity	2100 cd

Beam angle	40 °
Rated beam angle (half peak value)	40.00 °
Warm-up time (60 %)	0.00 s

Number of LEDs per module

Length	50.0 mm
Width	50.00 mm
Width (incl. round luminaires)	50.00 mm
Height	52.00 mm
Height (incl. round luminaires)	52.00 mm
Diameter	50,0 mm
Product weight	90.00 g

Ambient temperature range	-20…+40 °C
Maximum temperature at tc test point	85 °C
Temperature range in operation	-25…85 °C
Performance temp. acc. to IEC 62717	75 °C

Nominal lamp life time	50000 h
Number of switching cycles	100000
